  • Corsa PRO — CORSA PRO 55 620-940 HFX MD RMBK WH FP

Corsa PRO / CORSA PRO 55 620-940 HFX MD RMBK WH FP

22677485

▼ Data Sheet

Ultra-flexible and reliable downlights ideal for retail and hospitality application. Easy and reliable installation, aluminium ceiling recessed luminaire. Cut-off angle > 30°. 0-30° tilting angle, 0-355° rotatable. DALI dimmable, Class II electrical, IP20/54, Impact strength: IK03.. Fitted with 1 meter flex and plug.

Dimensions: Ø65 x 96 mm
Luminaire input power: 9 W
Luminaire efficacy: 69 lm/W
Weight: 0.01 kg

Mode selection
  • Lamp position:STD - standard
  • Light Source:LED
  • Luminaire luminous flux*:619 lm
  • Luminaire efficacy*:69 lm/W
  • Colour Rendering Index min.:90
  • Correlated colour temperature*:4000 Kelvin
  • Chromaticity tolerance (initial MacAdam):3
  • Rated median useful life*:L80 50000 h at 25 °C
  • Ballast:1x LED_DRV
  • Luminaire input power*:9 W Power factor = 0.9
  • Dimming:DaliDim
  • Maintenance category CIE 97:C - Closed Top Reflector
  • Total harmonic distortion (THD):20.00 %
  • LED
  • CCC
  • 850°
  • IK03
  • IP20_IP54
  • LED
  • RCM
  • SC2 - Protection Class 2
  • Ta = -20 to +45
